Arduino uno hardware spi pins. This can be quite useful to control some actuators that require a fine voltage tuning and are not only switched on or off. There is another location on the board for the mosi miso sclk pins. The spi s ss cs mosi miso and sclk connections are found on digital pins 10 to 13 respectively. But the recommended current is 20 ma.

This is on digital pins 11 12 and 13 on the uno and pins 50 51 and 52 on the mega. Can be connect to arduino using cat5 cable. Atmega328p freetronics includes both 3 3 v and 5 v regulators for shields d13 pin isolated with a mosfet of which can also be used as an input. On both boards pin 10 is used to select the hdg104 and pin 4 for the sd card.

In the arduino uno pins 3 5 6 9 10 11 have pwm capability. So you have 6 pins where you can create a pwm using the analogwrite function. Read air pressure and temperature from a sensor using the spi protocol. Pin 13 of the arduino uno is connected to the built in led.

Arduino uno compatible d13 pin isolated with a mosfet of which can also be used as an input. How to use arduino board. Each pin can provide sink up to 40 ma max. For example the arduino ethernet shield uses pin 4 to control the spi connection to the on board sd card and pin 10 to control the connection to the ethernet controller.

Arduino uno has 14 digital input output pins out of which 6 can be used as pwm outputs 6 analog input pins a usb connection a power barrel jack an icsp header and a reset button. Arduino uno has built in hardware support for spi communication. It is on the icsp header near the atmega chip. Pins 0 13 of the arduino uno serve as digital input output pins.

The arduino uno pins compatible with pwm are the pins 3 5 6 9 10 and 11. It s important to note that. Arduino communicates with both the wifi shield s processor and sd card using the spi bus through the icsp header. It has 14 digital input output pins of which 6 can be used as pwm outputs 6 analog inputs a 16 mhz ceramic resonator cstce16m0v53 r0 a usb connection a power jack an icsp header and a reset button.
